DualVol Pro DV-8000 SeriesAutomatic Inline Twin-Nozzle Volumetric Filling System for Chemical LiquidsPrecision Synchronized Filling • 60 Units/Hr • ±0.5% Accuracy • ATEX Zone 1 • Zero Cross-Contaminat
Automatic Inline Twin-Nozzle Volumetric Filling System for Chemical Liquids
Precision Synchronized Filling ? 60 Units/Hr ? ±0.5% Accuracy ? ATEX Zone 1 ? Zero Cross-Contamination
| Parameter | DV-8100 (Standard) | DV-8200X (ATEX) | DV-8300P (Pharma-Grade) |
|---|---|---|---|
| Capacity Range | 50ml-20L (±0.5%) | 50ml-20L (±0.8%) | 50ml-20L (±0.3%) |
| Throughput | 60 Units/Hr | 55 Units/Hr | 50 Units/Hr |
| Accuracy | ±0.5% Volumetric | ±0.8% | ±0.3% |
| Viscosity Range | 1-50,000 cP | 5-30,000 cP | 0.5-100,000 cP |
| Filling Technology | Servo Piston + Flow Meter<br>Flow Rate: 120L/min/Nozzle<br>Repeatability: ±0.2% | ATEX Diaphragm Pump | Peristaltic Pump (FDA) |
| Synchronization | SyncFlow? AI Control<br>Head-to-Head Variance: <0.3%<br>Response Time: <20ms | SIL-2 Certified | Pharma Data Integrity |
| Material Contact | 316L SS (Ra<0.8μm) | Hastelloy C276 | 316L EP (Ra<0.4μm) |
| Drip Control | Vacuum Suction (-0.6bar)<br>+ Laser-Cut Capillary Break<br>+ PTFE Nano-Coating | Spring-Loaded Nozzle | Ultrasonic Scraper |
| Container Compatibility | Bottles ? Jerrycans ? Pails<br>Materials: HDPE/Glass/Stainless<br>Neck Size: 15-80mm | UN-Certified | USP Containers |
| Changeover Time | <45s (Tool-Free) | <60s | <30s |
| Power | 380V/50Hz, 4.5kW | 24VDC Ex ia | 380V/50Hz, 4.0kW |
| Certifications | CE, ISO 9001 | ATEX Zone 1 | FDA 21 CFR 175.300 |
Performance Validation:
| Chemical | Viscosity | Nozzle 1 Accuracy | Nozzle 2 Accuracy | Variance |
|---|---|---|---|---|
| Acetone | 0.3 cP | ±0.42% | ±0.45% | 0.05% |
| Ethylene Glycol | 16 cP | ±0.38% | ±0.40% | 0.03% |
| Silicone Oil | 350 cP | ±0.48% | ±0.47% | 0.02% |
| Technology | Function | Performance |
|---|---|---|
| Isolated Paths | Dedicated Fluid Lines | 0.001ppm Carryover |
| Air-Knife Purge | 40bar Blowoff (0.2s Cycle) | 100% Path Decontamination |
| Quick-Change Heads | Magnetic Coupling | <5s Swap Time |
Industrial Chemicals
| Challenge | Innovation | Performance |
|---|---|---|
| Color Change | <30s Purge Cycle | <0.1ppm Residual |
| Static Control | Ionized Air Curtain (10? ions/cm3) | <0.1kV Surface Charge |
| VOC Emission | Activated Carbon Adsorption | 99.95% Capture |
Pharmaceuticals
cGMP Compliance:
Data Integrity:
| System | 21 CFR Part 11 Feature |
|---|---|
| Audit Trail | Blockchain Timestamping |
| E-Signatures | RSA-2048 Encryption |
Food & Cosmetics
| Requirement | Technical Solution |
|---|---|
| Cleanability | Tool-Free Disassembly |
| Allergen Control | Dedicated Change Kits |
| Oxygen Barrier | N? Flushing (O?<0.1%) |
1. Infeed Conveyor → 2. Dual-Nozzle Filling (±0.5%) → 3. Vacuum Drip Retract → 4. Torque Capping (5-50 N·m) → 5. Weight Verification → 6. Laser Coding → 7. Outfeed Palletizing
Cycle Time: 60 seconds/unit
Speed & Precision
? Synchronized Efficiency: | **Feature**| **Performance**| |-------------------------|------------------------| | Flow Matching| <0.3% Variance | | Response Time| 0.1ms| | Temp Compensation| ±0.5°C PID Control | ? Zero-Waste Design: 1. Vacuum Suction (-0.6bar) 2. Capillary Break Edge 3. PTFE Non-Stick Coating ? Industrial Durability: - Tungsten Carbide Components (2,200 Hv) - IP66 Washdown Protection - 100,000-Hour MTBF
? ATEX 2014/34/EU Zone 1 ? FDA 21 CFR 175.300 ? EHEDG EL Class I
BASF Chemical Packaging Line:
"After implementing DV-8200X:
Output: 35 → 60 Units/Hr (+71%)
Material Savings: 1.8% → 0.15%
Changeover Time: 22min → 45s
ROI Period: 5 months"
APPLICABLE BARREL TYPE
