GZB 鋁制單點傳感器 產品特點：
鋁合金稱重傳感器無色陽ji化處理;膠密封處理，防護等級IP65。鋁稱重傳感器是yi種低調的單點式稱重傳感器專為低成本稱重平臺低的直接安裝。它的體積小，結合精度高，成本低，這使得稱重傳感器非常適用于地上衡，電子地上衡，低調地磅，數字地磅，地上秤，地上天平秤，無框地板，框架型地坪規模，防爆地磅，可移動地磅，臺秤，牲畜秤，坑的規模，軌道衡，數字式地磅，數字重量平衡，電子秤的平衡，數字精密天平，數字計數秤，數字電子天平，數字yi體平衡，地磅，臺秤，嬰兒秤。
Technical Parameter:
| Rated Load: | 50kg~1000kg |
Sensitivity: | (2.0±0.1%) mV/V |
Combined Error: | ±0.03% F.S |
Creep Error30min: | ±0.03% F.S |
Zero Balance: | ±1% F.S |
Temp. Effect On Zero: | ±0.02% F.S/10 |
Temp. Effect On Span: | ±0.02% F.S/10 |
Input Resistance: | 385±5Ω |
Output Resistance: | 353±2Ω |
Insulation Resistance: | ≥5000MΩ |
Operating Temperature Range: | -30~+70 |
Maximum Safe Over Load: | 150%F.S |
Ultimate Over Load: | 200%F.S |
Recommend Excitation Voltage: | 10~12V DC |
Maximum Excitation Voltage: | 15V DC |
Sealing Class: | IP65 |
Element Material: | Aluminum |
Cable: | Length=L:3m |
Citation: | GB/T7551-2008/ OIML R60 |
